2) ONVIF protocols: Support 2.0 Version
3) With IR-CUT, support day/night switch
4) 2.0 megapixels
5) 2.8mm lens Default/3.6mm 6mm 8mm Optional
7) 24pcs F5 leds, 20m ir distance for night vision
8) Multi-screen software and CMS
9) Image processing: auto exposure(AE), auto white balance(AWB), auto gain control(AGC)
10) Support motion detection, ONVIF
11) Support visit by smart phone
1/2.5” = 1080P =2.0MP
• Title OSD: Supports channel name, date, and video stream information overlay;
• Privacy Mask: 4 configurable regions
• Image Orientation: image flip and mirror
• Auto Exposure Control (AEC); Auto White Balance (AWB); Auto Band Filter (ABF)
• Auto Black Level Calibration (ABLC)
• Network protocol: TCP/IP UDP RTP RTSP RTCP HTTP DNS DDNS DHCP FTP NTP PPPOE SMTP UPNP
• ONVIF protocols: Support 2.0 Version
• Remote View: IE 6.0 or later, Firefox, chrome
• Network Interface: 10/100M BASE-TX,RJ-45 connector
• Operating Temperature: -20 °C ~ 50 °C (-4 °F ~ 122 °F)
• Operating Humidity: 0% -85% RH
• Power: DC 12V 1A or 2A ( NOT INCLUDED )
Q:What’s the default ip address of the camera ?
F: 192.168.1.10 Username : admin Password : null ( empty ) !
Q: Does the camera supports Motion Detect,FTP,Email alarm, RTSP and so on ?
F: Yes ! All the IP Cameras we are selling supports these functions .
1) Please Setup the motion detection in the CMS software .
2) We suggest the Sever-U and FileZilla FTP Server to upload the image.
3) For the Email alarm,please use Email server which supports SMTP ( Hotmail ,Yahoo not support SMTP ,it not supports Gmail temperately since the server problem ) .
4) ,RTSP URL for VLC media Player :
Example : rtsp://10.6.10.25:554/user=admin&password=&channel=1&stream=0.sdp?real_stream
F: What’re the ports information of the cameras ?
Q : ONVIF 2.0 Port 8899 ;RTSP Port 554 ;HTTP Port 80;Media Port 34567
F:Does the camera support IE ,Chrome ,Firefox and so on ?
Q: Since the plug-in problem ,for website interface IP address URL,ONLY IE supports Multi Language . Chrome,Safari just support Chinese .
For cloud server XMEYE.NET ,it supports multi language
Q:When I finish the steps to add the camera to the CMS list,why it notify “ Can’t find the Device “ even I can see the default ip address 192.168.1.10 in the menu .
F: It is the IP Address conflict ,the default ip address is not in the same network segment as your router.
Please click “Edit Device “ to change the camera’s ip address to make them in the same network segment !
For example ,if your router’s ip address is 192.168.0.1 ,then you need to change the camera’s ip address to 192.168.0.XX .
1 * IP Camera
1 * CD
PC and Phone Online VIew Operation Manual
