Processor | HI 3516C + SONY IMX323 | |
Image sensor |
1/2.7″ 2.0 MP CMOS (Low Illumination,Better Night Vision) |
|
Lens | 3.6mm(default)2.8mm 6mm 8mm |
|
IR Distance | 20 meters | |
Power Consumption | DC 12V 1A | |
Working Temperature | -20℃~+55℃ | |
Working Humidity | <95% | |
Weight | 0.5KG | |
Video | Video Codec | H.264 main profile and baseline |
Video Resolution | 1080P | |
First stream:1920×1080/ 1280×720 |
||
Second stream:640×352 | ||
Frame Rate | PAL:25fps(50HZ),NTSC:30fps(60HZ) | |
Video Compression | 32Kbits/s ~ 6Mbits/s | |
Min. Lux | 0.1Lux | |
Audio (Optional) | Audio input | 1 ch Line/Mic |
Audio output | 1 ch Line out | |
Audio Codec | G.726/G.711 | |
Network | Interface | RJ45, DC Power |
Network Protocol | TCP/IP, HTTP, TCP, ICMP, UDP, ARP, IGMP, SMTP, FTP, DHCP, DNS, DDNS, NTP, UPNP, RTSP, ect. | |
Access Protocol | ONVIF 2.1, i13, P2 | |
Alarm | Motion detection | 4 respective regions at most |
Alarm linkage | Send alarm pictures by E-mail or upload to FTP server | |
Snapshot | Supports regularly capturing images to FTP server | |
Safety | User management | Provides three levels of rights management (admin, user, guest). Supports modify login user name and password |
External Port | Audio Output | NO |
Video Output | VGA*1+HDMI*1 | |
RJ45 Interface | 1*100M RJ45 | |
RS485 Interface | NO | |
USB | 2*USB2.0 | |
Alarm Input | NO | |
Alarm Output | No | |
HDD | 1*3.5″HDD | |
Remote View | Support IE browser,Smart phone,CMS and P2P | |
Power Consumption | DC12V/2A,≤35W(Without HDD) | |
Working Temperature | -10℃~+55℃ | |
Working Humidity | 10%-90% | |
Size(Without Package) | 200×200×30mm(W×D×H) |
